Lineare combinato che consente la saldatura da ambo i lati del giunto
|
Model SWC |
Welding Length mm |
Min. Ferrule diameter outside welding mm |
Max. Ferule diameter outside welding mm** |
Min. Ferrule diameter inside welding mm |
Max. Ferrule diameter inside welding mm |
Carriage Speed Min. - Max. mm/min |
Length mm |
Width mm |
Height mm |
|---|---|---|---|---|---|---|---|---|---|
| SWC 1.0 | 1100 | 80 | 800 | 1200 | No limits | 0 - 30000 | 2300 | 800 | 1900 |
| SWC 1.5 | 1600 | 110 | 800 | 1300 | No limits | 0 - 30000 | 2800 | 800 | 1900 |
| SWC 2.0 | 2100 | 150 | 800 | 1300 | No limits | 0 - 30000 | 3300 | 1000 | 1900 |
| SWC 3.0 | 3100 | 260 | 1000 | 1500 | No limits | 0 - 18000 | 4300 | 1000 | 2100 |
| SWC 4.0 | 4100 | 340 | 1000 | 1500 | No limits | 0 - 18000 | 5300 | 1200 | 2100 |
