Trave motorizzata nello spostamento lungo gli assi orizzontale X e verticale
|
Model MWB on rails |
Vertical Stroke mm |
Horizontal Stroke mm |
Height Total mm |
Horizontal Beam Speed mm/min |
Vertical Beam Speed mm/min |
Basement on wheels Width x Length |
|---|---|---|---|---|---|---|
| 2.0 x 2.0 | 2000 | 2000 | 3300 | 0 - 6000 | 3000 | 1500 x 1500 |
| 3.0 x 3.0 | 3000 | 3000 | 4300 | 0 - 6000 | 3000 | 1700 x 1700 |
| 4.0 x 4.0 | 4000 | 4000 | 5900 | 0 - 5000 | 1500 | 2200 x 2200 |
| 5.0 x 5.0 | 5000 | 5000 | 6900 | 0 - 5000 | 1500 | 2200 x 2200 |
| 6.0 x 6.0 | 6000 | 6000 | 7900 | 0 - 4000 | 1000 | 2850 x 2900 |
| 7.0 x 7.0 | 7000 | 7000 | 9000 | 0 - 3000 | 1000 | 2850 x 2900 |
